Electromagnetic drills are an indispensable help for the assembly of steel structures, bridges, etc., where it is necessary to drill the holes and the "footwear" at heights, which is often not achievable using a conventional method – a hand drill. Especially if it is necessary to drill a larger hole diameter.

MODEL MAGBEAST HM100T

An electromagnetic drill not only capable of drilling and threading, but also of cutting, turning, boring and threading the holes.

High-performance engine with a power output of 1,800 W
2-speed variable gearbox with reverse operation
Range of 250 mm drilling path
Elegant, ergonomical design
Maintenance-free double slip rails
Strong protective guard
Simple and efficient control panel
Powerful electromagnetic base
360° rotating base option

MODEL SPECIFICATIONS

Model	HM100T	HM100TS with rotating base
Spindle	MT3	MT3
Weight	23.5 kg	27 kg
Max. Stroke	250 mm	290 mm
Knife capacity	100 mm L x 6” cutting depth	100 mm L x 6” cutting depth
Spiral drill	19 mm with 3MT chuck ~ 32 mm with 3MT spiral drill	19 mm with 3MT chuck ~ 32 mm with 3MT spiral drill
Dredging capacity	55 mm	55 mm
Thread capacity	M30	M30
Reamer	39 mm	39 mm
Motor	1,800 W	1,800 W
ROM	2 variable speeds (torque control) 60-140 / 200-470	2 variable speeds (torque control 60-140 / 200-470
Rotating base	Unavailable	360°
Height min./max.	450 / 700 mm	495 / 740 mm
Length x width	345 x 190 mm	345 x 190 mm
Magnetic base L×W	212 x 102 mm	212 x 102 mm
Noise emissions	< 90 dB	< 90 dB
Vibrations	< 2.5 m/s2	< 2.5 m/s2
Voltage:	110 V – DRILL-HM100T – 240 V – DRILL-HM100T/2	110 V – DRILL-HM100T – 240 V – DRILL-HM100T/2
Transport weight	28.65 kg	32 kg
Transport dimensions	571 x 450 x 250 mm	571 x 450 x 250 mm
